Miller OBT-600 - Specifications; Welding Torches; Overall Dimensions

OM-1596 Page 3
SECTION 2 – SPECIFICATIONS
2-1. Welding Torches
Model
Rating: 100%
Duty Cycle DCEP
Wire Diameter Capacity
Cooling
Method
Weight
Model
Rating: 100%
Duty Cycle DCEP
Wire Diameter Capacity
Cooling
Method
Net
OBT-600
600 Amperes
Submerged Arc
1/16, 5/64, 3/32, 7/64, 1/8, 5/32, 3/16, 7/32 in
(1.6, 2.0, 2.4, 2.8, 3.2, 4.0, 4.8, 5.6 mm) Hard Wire
Air
2 lb
(0.91 kg)
OBT-1200
1200 Amperes
Submerged Arc
1/16, 5/64, 3/32, 7/64, 1/8, 5/32, 3/16, 7/32 in
(1.6, 2.0, 2.4, 2.8, 3.2, 4.0, 4.8, 5.6 mm) Hard Wire
Air
7 lb
(3.2 kg)
14-3/4 in
(374.7 mm)
17-1/4 in
(438.2 mm)
10-1/4 in
(260.4 mm)
11-1/4 in
(285.8 mm)
SA-802 264-A
OBT-1200 Model
OBT-600 Model
2-2. Overall Dimensions
7-1/2 in
(190.5 mm)
