Milltronics MD-2000A - MD-2000 A SS Outline Dimensions

( ref. )
76 mm
( 3" )
216 mm
( 8.5" )
102 mm
( 4" )
16 mm ( 0.63" )
Ø shaft
114 mm
( 4.5" )
127 mm
( 5" )
86 mm
( 3.4" )
6 mm ( 0.25" )
Ø shaft
(2 places)
61 mm
( 2.4" )
152 mm
( 6" )
76 mm
( 3" )
239 mm
( 9.4" )
152 mm
( 6" )
19 mm
( 0.75" )
21 mm
( 0.8" )
38 mm
( 1.5" )
51 mm
( 2" )
76 mm
( 3" )
cable connector
for 3 to 9 mm (.125"
to .25") o.d. cable
127 mm
( 5" )
MD - 2000A SS OUTLINE
