Milltronics MD-2000A - MD-2000 A Outline Dimensions

TRONICS
MILL
TRONICS
MILL
( ref. )
61 mm
( 2.4")
213 mm
( 8.4" )
112 mm
( 4.4" )
16 mm ( 0.63" )
Ø shaft
114 mm
( 4.5" )
117 mm
( 4.6" )
124 mm
( 4.9" )
6 mm ( 0.25" )
Ø shaft
(2 places)
61 mm
( 2.4" )
142 mm
( 5.6" )
71 mm
( 2.8" )
218 mm
( 8.6" )
142 mm
( 5.6" )
71 mm
( 2.8" )
21 mm
( 0.8" )
84 mm
( 3.3" )
56 mm
( 2.2" )
1/2 NPT plug
(2 places)
MD - 2000A OUTLINE
PL-361
4
92/12/08
