C
HAPTER
2 - S
PECIFICATION
17
1 Operator panel
2 Spindle
3 ATC, Carousel and ARM types
4 Auger Chute
5 Electrical cabinet
6 Y-axis cable track
7 Z-axis cable track
8 Leveling pad
9 Waylube unit
10 Air system
11 Z-axis motor
