Milnor MCR12E5 - Page 11

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
BMP050007/2009412B
(Sheet 1 of 2)
Guards and Covers MCR12E5, MCR18E4,MCR16E5, MWR16E5,MWR12E5, MWR18E4, MWR18X4, MWR18J4
REAR
TOP
FRONT
RIGHT
5
4
3
3
(LEFT &
RIGHT SIDES)
7
6
1
(LEFT &
RIGHT SIDES)
2
7
1
6
2
CH
MWR18X4 EP EXPRESS & CONTROLS NOT SHOWN MWR18J4 EP PLUS
8,9
4 PLACES
