Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Guard & Covers
BMP050007/2009412B
(Sheet 2 of 2)
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A GHG575X347 2314 CABINET ASSEMBLY 9KG MCR12E5
B GHG2318001 2318 CABINET ASSY 16KG MCR16E5
C GHG700X468 CABINET 18KG MCR18E4
D GHG9KGOPL CABINET 9KG-OPL MWR12E5
E GHG2318002 2318 CABINET 16KG OPL MWR16E5
F GHG18KGOPL CABINET 18KG-OPL MWR18E5
MWR18X4
MWR18J4
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
A 1 03 40001 CABINET FRONT 575X347
B 1 03 40101 CABINET FRONT 16KG
C 1 03 40201 CABINET FRONT 18KG
D 1 03 40001A CABINET FRONT 9KG-OPL
E 1 03 40101A CABINET FRONT 16KG OPL
F 1 03 40201A CABINET FRONT 18KG-OPL
AD 2 03 40002 PANEL SIDE STAINLESS 9KG
BE 2 03 40102P CABINET SIDE 16KG C/S (COLOR=WARM GRAY)
CF 2 03 40202 PANEL SIDE STAINLESS 18KG
AD 3 03 40003 CABINET TOP 575X347
BE 3 03 40103 CABINET TOP 2318
CF 3 03 40203 CABINET TOP 700X468
AD 4 03 40004 CABINET REAR VAL MT 575X347
BE 4 03 40104 CABINET REAR MTBKT 2314
CF 4 03 40204 CABINET REAR MTBKT 700X468
AD 5 03 40027 CABINET BACK COVER 575X347
BE 5 03 40127 CABINET REAR GUARD 16KG
CF 5 03 40227 CABINET REAR GUARD 18KG
AD 6 03 40040 LOWER FRONT GUARD 9KG
BE 6 03 40140 LOWER FRONT COVER 16KG
CF 6 03 40240 LOWER FRONT COVER
AC 7 03 40040A PANEL LOW STAINLESS 9KG
BE 7 03 40140P LOWER SIDE COVER LF/RT C/S (COLOR=WARM GRAY)
CF 7 03 40240A PANEL LOW STAINLESS 18KG
all 8 15K120M HXCAPSCREW M8X40 8.8 FULTH
all 9 17N070M CAGE NUT M8 1.8-3.2MM THK
