Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Bearing Assembly & Installation
BMP100028/2010316B
(Sheet 2 of 2)
-------------------------------------------------------------------COMPONENTS--------------------------------------------------------
all 1 ABM30011 ASSY=BEARING HOUSE 2818MG
all 2 ABM30013 ASSY=WTR SEAL HOLDER, 2825-LS
all 3 ACA2818CYL CYLINDER ASSY WELDED 2818
all 4 60C160J ORING 6+1/4ID1/8CS BUNA70 #259 PART OF ITEM 2
all 5 60C166B ORING 7.00ID1/8CS BUNA70 #262
all 6 20H012A ALVANIA EP-2 LF EA=1 TUBE
all 7 15K052M HEXCAPSCR M8*25 STAINLESS
all 8 15U200S FLATWASHER US STD 5/16 SS18-8
all 9 24G027N ROLLED WASH.312ID NYLTITE 31W
all 10 15K071M HEXCAPSCR M8*35 STAINLESS
all 11 15K191M HEXCAPSCR M12*55 GR10.9 CS
all 12 15G230M HEXNUT M12 GRADE 10.9 CS
all 13 15U317B FLWASH,1.062ODX.531IDX.115 TH
all 14 02 04505 3010 BEARING HOUSE SHIM
all 15 5N0E02KG42 NPT NIP 1/4X2.5 TBEGALSTL SK40
all 16 51E507 HOSESTEM BRASS 1/4MPX1/2HOSEID
all 17 60E006C PVC TUBING NYL.REINF.5IDX.75OD
all 18 27A040 HOSECLAMP 7/16-25/32SS W/SCREW
all 19 15B200M HEXCAPSCR M20-2.5 X 40M 18-8
all 20 15U350M LOCKWASHER M20 18-8S/S
all 21 98CMCR0950 SHAFT RETNR SPACER METRIC
all 22 98CMCR0949 COVER SHAFT RETAINER METRIC
all 23 24S053 SEAL 2.625X3.625X.437#10051L5 PART OF ITEM 2
PART OF ITEM 2
