PELLERIN MILNOR CORPORATION
DOOR
LOCK
SOLENOID
DOOR
LOCK
SWITCH
SEE
DETAIL C
SEE
DETAILS
A&B
1
DOOR
CLOSED
SWITCH
PELLERIN MILNOR CORPORATION
Figure 1: Components
BMP130002/2016434A
Door Lock Mechanism
MCR27E5, MWR27E5; 3015T6X,VRJ,V8Z,VZZ; 30022T6X,VRJ,V8Z,VZZ; MWF27J8, MWF27Z8; 30022X8R
36021V5Z, 36021V7Z, 36026V5Z, 36026V7Z, 42026V6Z, 42030V6Z
79
