Part I Service Scenarios
Repair 88
Error code Overview
Monitoring Point
Name
Module
V1011 Power monitoring DSP_Vccaux Main board
V1012 Power monitoring DSP_Vccint Main board
T1000 Temperature monitoring FPGA Main board
T006 Temperature monitoring CPU temperature CPU module
F1001 Fan monitoring FAN1_TACH_CON Main board
F1002 Fan monitoring FAN2_TACH_CON Main board
F1003 Fan monitoring FAN3_TACH_CON Main board
F1004 Fan monitoring FAN4_TACH_CON Main board
F1005 Fan monitoring FAN5_TACH_CON Main board
F1006 Fan Control FAN_BATTERY0 Main board
F1007 Fan Control FAN_BATTERY1 Main board
E012 Operating error Key_Stuck Control panel
P001 Program-controlled voltage PHV1P Main board
P002 Program-controlled voltage PHV1N Main board
P003 Program-controlled voltage PHV2P Main board
P004 Program-controlled voltage PHV2N Main board
P005 Program-controlled voltage PHV1P_PHV2P Main board
P006 Program-controlled voltage PHV1N_PHV2N Main board
P009 Program-controlled voltage HVP Main board
P010 Program-controlled voltage HVN Main board
P014 Program-controlled voltage PHV_OVP_H Main board
P016 Program-controlled voltage PHV1P_VP Main board
P017 Program-controlled voltage PHV1N_VP Main board
P018 Program-controlled voltage PHV2P_VP Main board
P019 Program-controlled voltage PHV2N_VP Main board
P024 Program-controlled voltage PHV1P_OPP_OCP Main board
P025 Program-controlled voltage PHV1N_OPP_OCP Main board
P026 Program-controlled voltage PHV2P_OPP_OCP Main board
P027 Program-controlled voltage PHV2N_OPP_OCP Main board
P1003 Program-controlled voltage HV_OPP_OCP Main board
P1004 Program-controlled voltage PHV_HV_PF_N Main board
P1001 Program-controlled voltage CWP Main board
P1002 Program-controlled voltage CWN Main board
P1020 Program-controlled voltage CWP_VP Main board
P1021 Program-controlled voltage CWN_VP Main board
