Part I Service Scenarios
Repair 93
3.2.2 System Startup Failure
3.2.2.1 Involved Modules or Boards
No. Description Remarks
1. Main board /
2 SSD/Hard disk /
3 PC assembly /
3.2.2.2 Information to Be Collected
No. Information to Be Collected Remarks
1. Mindray backlight on the rear side of the
main display
Mindray logo on the equipment
2 FPGA configuration indicator on the rear
side of the main board
This indicator is on the rear side of the main
board.
3 Startup screen Startup failure screen
To Next Page
