3. Cable between the control panel and the touch screen
Open the cable crimps and take off the two cables connected between the control panel and the
touch screen.
4. Power button
Pull out the power keypad and remove the power button cable from the interface.
FPC flat cable between
the main board and the
control panel
Cable crimp
Cable between the control panel
To Next Page
