Part II General Information

Structure and Assembly/Disassembly 194

4. Power button

Pull out the power keypad and remove the power button cable from the interface.

5. Trackpad

Cable crimp

Cable between the control panel

d the touch screen

Power keypad

Power button cable

Default Chapter3
