40
Procedures
Press the key.
The “SPAN” on the load display flashes on and
off, and span adjustment can be started.
12
Warning ： Take care not to apply load
variations due to vibrations and so on.
If load variation is applied, the span will
not stabilized, in due course there is a
possibility that correct reading of span
won’t be obtained.
When completed, the display on the load display
shows “END”.
However, when the value corresponding to the
maximum display value does not satisfy the
range from 0.2 mV/V to 3.1 mV/V, the right
Error code lights up for about 2 seconds, then
the display on the load display section shows
“SPAN”, and then returns to the step 10.
SP−L：Span point −OVER
SP−H：Span point ＋OVER
Error code
Error code
Press the key.
After “LCAL” mode is over, the load display
shows the present load.
13
To Next Page
