Minghe Electronic Technology B3603 - Usage; Simple Usage; Fully Functional Usage

Output current: 0 ~ 3A
Voltage regulation/display resolution: 0.01 V
Current regulation/display resolution: 0.001 A
The minimum display resolution of power: 0.001 W
The minimum display resolution of capacity: 0.001 AH
Conversion efficiency: up to 92%
The output ripple:
≦
50 mV
Working temperature: - 40
℃
~ + 85
℃
Working frequency:150 KHz
Short circuit protection:Constant current
Input reverse connect protection:No, if necessary please install diode
Connection mode: Terminals
Size (mm):66 (long)* 50 (wide) * 21 (high)
Weight: 43 g
Usage:
This module has two kinds of usage: one is simple usage,another is fully functional
usage.
Simple usage:
1
、
Properly connect input,output,and guarantee the input voltage in the range of
requirements.It is forbidden to reverse connection, or it will be burn out.
2
、
Setting the voltage and current value,the setting method as follows:
After electrify, the LED default display the voltage value,the format of voltage display
is "00.00", press "SET" button to switch to the current value,the format of current
value display is "0.000". Press the button increase the value ,press the button
reduce the value, short press the button can accurate r
egulation
, long press the button can
quickly regulate.If the voltage or current value has been changed, press the "SET"
button the LED display the "----"said that the voltage or the current has been saved . If
there is no change of voltage or current value, press "SET" key to switch to the
current or voltage value.
3
、
After finish setting, press the "OK" button to output.
4
、
In the output state, press the button can increase the output voltage value and
press the button can reduce the output voltage value when the LED display the
voltage value,press the button can increase the current value and press the button
can reduce the current value when the LED display the current value,short press the
button can accurate r
egulation
, long press the button can quickly regulate. In the output
state, short press "OK" button can switch display parameters such as voltage, current,
power, capacity, long press for 3 seconds will automatically take turns to show, long
press"OK"button again can cancel the take turns to show.In the output
state,the and button is invalid
5
、
In the output state, press the "SET" button to close the output.
Fully functional usage:
