This module has three special functions, the default is closed, if necessary, you can
open them.
Function 0:After electricity,it will automatically output.
Function 1: Save and bring up the parameters, display the power and capacity.
Function 2: Automatic take turns to show parameters after output
Open/close method:
Long press the"OK" button, then to the module electricity, the LED will take turns to
show in "
--0-
"~"
--2-
" , when display "
--0-
" ,release the"OK" button will open or
close function 0, when display "
--1-
" ,release the"OK" button will open or close
function 1, when display "
--2-
" ,release the"OK" button will open or close function 2.
After releasing the "OK" button the digital tube display "
--y-
" said already open the
current function, the display "
--n-
" said it already close the current function.
1
、
Enable the function 0 it will automatically output after electricity.
2
、
Enable the function 1, in the condition of no output, press "SET" button will take
turns to show among voltage "00.00", current "0.000", bring up the parameters "Lo.-
0" and save the parameters "SA.- 0". Below illustrate this function:
For example:we need store10V, 1.5 A in the storage location 1 and bring up the
parameter from storage location 1.
1 Press "SET" button to switch to the voltage value, setting voltage value of
10.00 V, press "SET" button to save the voltage value.
2 Press "SET" button to switch to the current value, setting current value of
1.500 A, press "SET" button to save the current value.
3 Press "SET" button to switch to the "SA.-0", press the or button to select
the storage location, here need to adjust to "SA.-1", press "OK" button to store the "10
V, 1.5 A" in the storage location 1.
4 Press "SET" button to switch to "Lo.-0", press the or button to select the
storage location which the parameter need to bring up, here need to adjust to "Lo.-1",
then press the "OK" button to bring up the parameters of storage location 1.
5 This module has total of 0 ~ 9 common 10 groups of storage location, the
storage location can be set arbitrary voltage and current value.
3
、
Enable the function 2,after output,it will automatically take turns to display the
parameters such as voltage, current, power and capacity.
Note:
1
、
Properly connect input and output, it is forbidden to reverse connection, or it will
be burn out.
2
、
This module is a step-down module, input voltage need over output voltage more
than 1.5 V.
3
、
Output under 2A natural cooling, output above 2A shall strengthen heat dissipation.
Display:
00.00: voltage value ,00.00 ~ 36.00 V
0.000: current value, 0.000 ~ 3.000 A
P. 000, P0.00, P00.0, P000. : power value, unit W, the position of the decimal point as
