luggage load capacity is 650 lbs (1,400 -
750 (5 x 150) = 650 lbs)
5. Determine the combined weight of lug-
gage and cargo being loaded on the ve-
hicle. That weight may not safely exceed
the available cargo and luggage load ca-
pacity calculated in Step 4.
6. If the vehicle will be towing a trailer,
load from your trailer will be transferred
to the vehicle. Consult this manual to
determine how this reduces the availa-
ble cargo and luggage load capacity of
the vehicle.
Payload
On 3-door models
On 5-door models
The maximum payload is the sum of the
weight of the occupants and the cargo.
The greater the weight of the occupants, the
less cargo that can be transported.
Stowing and securing cargo
– Cover sharp edges and corners on the
cargo.
– Heavy cargo: stow as far forward as pos-
sible, directly behind and at the bottom
of the rear seat backrests.
– Very heavy cargo: when the rear seat is
not occupied, secure each of the outer
seat belts in the opposite buckle.
– Fold down the rear seat backrests com-
pletely to stow large cargo.
– Do not stack cargo above the upper edge
of the backrests.
– Small and light cargo: secure with lug-
gage straps or draw straps.
– Larger and heavy cargo: secure with
cargo straps.
Lashing eyes in the cargo area
Without storage compartment package: to
secure the cargo there are two lashing eyes,
arrows 1, in the cargo area.
With storage compartment package: to se-
cure the cargo there are six lashing eyes,
arrows 1 and 2, in the cargo area.
Attach auxiliary materials to secure the
cargo, such as lashing straps, tensioning
straps, draw straps or cargo nets, to the
lashing eyes in the cargo area.
Seite 228
CONTROLS Cargo area
228
Online Edition for Part no. 01405A7DAD4 - II/23
