Lower position
– Larger objects can be transported.
– Space for smaller objects remains be-
tween the fixed and variable cargo area
floor.
Folded up position
Safety information
Warning
Improper use of the cargo area floor can
lead to a risk of objects flying about
during braking and evasive maneuvers,
for example. There is a risk of injury and
risk of damage to property.
– Do not use the cargo area floor to
separate the cargo area and vehicle
interior in the sense of a luggage net.
– Only use the cargo area floor in the
folded-up position when the rear seat
backrests are folded up and locked.
– Fold down the cargo area floor before
driving off.
– Always secure cargo against slipping,
using straps, belts and lashing eyes,
for instance.
Fold up the cargo floor panel
Fold up the cargo floor panel in the lower
position and push it behind the locks, arrow.
You've reached the maximum cargo height.
Upper position
– With the backrests folded down, a long,
flat loading platform is produced.
– For 3-door models:
Maximum payload in this position:
330 lbs/150 kg.
– For 5-door models:
Maximum payload in this position:
441 lbs/200 kg.
– Space for objects remains between the
fixed and variable cargo area floor.
Seite 232
CONTROLS Cargo area
232
Online Edition for Part no. 01405A7DAD4 - II/23
