ATTACHING THE FAN BLADES
Insert one fan blade into the blade slot on the motor housing and secure
with the blade support plates and screws. Securely tighten screws. Repeat
process with other blades. (Fig. 15)
Fig. 15
FAN BLADE
SLOT
BLADE SUPPORT PLATES
SCREWS
