Mipro MA-101 - VHF Bodypack Transmitter Battery Installation; UHF Bodypack Transmitter Parts Identification

1.AFInputJack:Connectstoalavaliereorheadsetmicrophone.(See5ways
ofconnectiononAFInputConnections)
2.PowerSwitch:SwitchtoONpositionforoperation.SwitchtoOFFposition
whennotinuse.
3.BatteryStatusIndicator:Indicatesthepoweron/offandbatterystatus.
(a)Whenpowerswitchisturnedon:TheLEDindicatorflashesbriefly,
indicatingnormalbatterystatus.
(b)WhenREDlightilluminatesateitherpoweronorduringusage:The
batterylevelislow,therefore,anewbatteryreplacementisthusnecessary.
4.TransmitterHousing:PackagesthePCBandbattery.
5.GainControl:Adjuststhedesirousinputgain.
6.GT/MTLevelSelector:SwitchGTpositionforelectricguitarusageONLY.
GainControlisirrelevantfor"GT".Switchto"MT"forcondenser
microphone,wiredmicrophone.GainControlworksin"MT"forinput
sensitivityadjusting.
7.BatteryCompartmentandCover:Accommodatestwo1.5V(AA)batteries.
16 17
1.Pushingdownbothsnaplocksonthesidesofbatterycovertoopenbattery
cover.Takeoutthebatteries.Fig.5).
2.Insertatwo1.5(AA)batteriesintothebatterycompartmentaccordingtothe
correctpolarityasshowninFig.5).Thenpushuptoclosethebattery
compartmentasshowninFig.6).
4.BATTERYINSTALLATION
(Fig.5)
(Fig.6)
PS:Whenthemicrophoneisnotinuse:
Makesurethepowerofthemicrophoneisoff.Ifthemicrophonewillnotbe
usedforsometime,pleaseremovethebatteriesfromthebatterycompartment
toavoidbatteryleakageandresultindamagedbatteryspringsandcircuit.Ifa
rechargeablebatterywasused,takeitoutandrechargeit.
17
1.PARTSNAMESANDFUNCTIONS
(Fig.1)
5
6
9
7
4
1
2
3
8
BodypackTransmitterBodypackTransmitter
