Wireless Mic System
Turn on master Power switch. Power indicator glows red. Ready for operation.
Turn on CH1 VOL or CH2 VOL switch.
Turn transmitter power on. Ensure fresh alkaline or lithium batteries (not
included) are installed.
CH1 RF indicator or CH2 RF indicator glows green after the transmitter is
turned on to denote a successful RF link.
Adjust CH1 VOL or CH2 VOL to desired volume.
Ensure receiver and transmitter have the same matching operating channels.
Notes:
1. Same wireless microphone can transmit to multiple MA-505 systems on the
same channel for a wider and expanded coverage.
2. It is not possible to transmit two wireless microphones on the same channel
to MA-505 system. Only one transmitter can be used at a time on that
channel. Be sure to turn off one of the two transmitters to avoid
interference.
!
!
!
!
!
!
OPERATING INSTRUCTIONS
Tips & Warning
After pairing, some devices will connect immediately. Others will ask you if you
want to connect.
If you move the wireless device out of the Music Receiver's range, the
connection will be lost and the indicator light will go off. If you move the
wireless device back into range, the connection will re-establish itself.
The Bluetooth music player can only play music from one device at a time.
Clean only with a dry cloth.
Do not expose the device to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill into any
openings.
!
!
!
!
!
08
09
PORTABLE WIRELESS PA SYSTEM PORTABLE WIRELESS PA SYSTEM
PAIRING BLUETOOTH MUSIC RECEIVER
OPERATING INSTRUCTIONS
Wired Microphone
Plug optional MIPRO MM-107 wired dynamic microphone with a 6.3mm (1/4”)
connector to MIC IN.
Turn on master POWER and adjust to desired volume.
Line Input
Available to connect an external CD, MP3, iPod or cassette player.
Connect a 3.5mm(mono)-to-3.5mm(stereo) audio cable (not included) to the
LINE-IN jack.
Turn on master POWER.
Adjust LINE VOL to desired volume.
Alarm Siren
Press Alarm button for warnings of approaching or presence of threats or
situations requiring immediate attention. This is an ascending sound of an
alarm.
Alarm will sound only when master Power is powered on and one of below
function is powered on.
1. Wireless transmitter and CH1 or CH2 are powered on.
2. Wired microphone is plugged into the Mic input and powered on.
3. USB player is powered on & music is playing.
!
!
!
!
!
!
!
!
To Next Page
