Mipro MA-707 - Belt Pack Transmitter Battery Installation

Belt Pack Transmitter
Operating Manual
- 18 -
Battery Installation
1. Pushing down both snap locks on the sides of battery cover to open battery cover.
Take out the batteries. Fig.(3).
2. Insert a 9V battery into the battery compartment according to the correct polarity as
shown in Fig. (4). Then push up to close the battery compartment as shown in Fig.
(4).
(Fig.3)
(Fig.4)
