Chapter 4 Mx-Series Unit Description
4-33
• Types
<Figure 4-17> shows the available standard nozzle units.
<Figure 4-17A Type H-4C Nozzle >
<Figure 4-17B Type A Nozzle>
<Figure 4-17C Type B-1 Nozzle>
<Figure 4-17D Type C Nozzle>
