Chapter 6 Programming 6-39
Centering
Inspects just one line of the balls on 4 edges of BGA part.
Lead Spacing Tolerance
Inspects the entire balls of BGA part.
Best Fitting
Inspects the entire balls of BGA part.
[Odd Shaped parts]
<Figure 6-33 가 Add new part -Odd Shape>
• General Tab: Enter package name or dimension.
• Lead Tab: Enter lead data of package.
