32
Specifications
KXO-Dual, and KXO-Dual3
KXO-Dual, and KXO-Dual3
Kaleido-X (4RU) Frame
Contact closure current 50 mA max
Reverse voltage -15 Volts max
Reverse current -50 mA max
V out low 0.6 Volts at 1.5mA
GPI bidirectional (up to 72) (continued)
ETHERNET
Signal 10/100 BASE-T (IEEE 802.3)
Connector RJ-45
RS-422/485
Signal RS-422 (SMPTE ST 207, EBU-3245), RS-485
Connector RJ-45
USB (4 connectors)
Signal USB Version 1.0
Connector USB
Power supply Hot-swappable redundant power supply
Input voltage 90-264 V
Frequency 47-63 Hz
Max current 15A
Max Power out 1200 W @ 230 Vac
Dimensions H: 175 mm (7 in) (4 RU)
W: 448 mm (17.64 in) + mounting flange for standard
19
in rack
D: 527 mm (20.75 in)
Full spec. temperature
range
0-35°C (32°F-95°F) (ambient)
Storage humidity 90% RH non-condensing
Functional humidity 65% RH non-condensing
Weight (bare frame) 10 kg (22 lbs)
