USER’S GUIDE
14 | Kaleido Remote Control Protocol (Gateway)
Where ChannelName is the full path to the source (channel) currently assigned to the
specified monitor. Ex.: /Input A/Channel 1.
<nack/>: The Gateway was not able to recognize the command, or a parameter could not
be resolved.
setKChannel KX K2 AQ
This command is used to assign a logical source (channel) to the specified monitor in the current
layout.
<setKChannel>set channelname=ChannelName monitor=MonitorNumber
</setKChannel>
Where:
o ChannelName is the name of the logical source you wish to assign to the specified
monitor. On a Kaleido-X series multi-viewer this is the full path to the source (channel).
Ex.: /Input A/Channel 1.
o MonitorNumber is the identifier of the monitor to which the source is to be assigned.
On a Kaleido-X series multi-viewer the monitor number must be prefixed with the room
name and a “/” if the session does not have a room context. Ex.:
Room1/composite42. The monitor name is available in the XEdit layout (Properties
> Assignments > Name).
Note: On the Kaleido-K2, to get the monitors’ identifiers for your current layout press the Tab key
on the keyboard, or the SELECT key on the RCP.
Gateway response:
<ack/>: The command was recognized by the Gateway.
<nack/>: The Gateway was not able to recognize the command, or a parameter could not
be resolved.
setKDynamicText KX K2 AQ
This command is used to set the text of a UMD or text label component that is configured to use
dynamic text. Note that the Service ID for this component must be set to “Gateway” when the
layout is created in KEdit/XEdit in order for this command to work.
<setKDynamicText>set address=Address text=NewText </setKDynamicText>
Where:
o Address is the configured text address of the UMD or text label component.
Note: The Kaleido-Alto/Quad/Quad-Dual systems require a numeric value in the range
0-1024. The Kaleido-K2 and Kaleido-X series do not have this limitation.
o NewText is the text to display.
Gateway response:
