Dimensions










Theinformationcontainedhereinisbasedonsourcesthatwebelievetobereliable,butisnotguaranteedbyus,
maybeincompleteand/ormaychangewithoutnotice
. 
Needtechnicalsupport?1(888)651‐2534
A Floortoceilingheight variable
B
Floor to counter top height
(standard)
36’’
C
Recommended height between
cooking surface and bottom of
thehood
28to30’’
D Hoodheight 1¾(total10½’’)’’
E Chimneyheight 2x19½’’
Installation
Ducttransition
1¾’’
8,66’’
5
Total:10½’’
29½’’
17.7’’
2x19½’’
Top6’’round


