2. INSTALLATIONINSTRUCTIONS

TOOLSNEEDEDTOINSTALLTHERANGEHOOD

 Phillipsscrewdriver
 Hammerandflatbladescrewdriver
 Sheetmetalsheers
 Pairofpliers
 Scissors(tocutducttape)
 MetalDucttape
 Markerorpencil
 Level
 Measuringtape

BEFOREINSTALLINGTHEHOOD

 Forthemostefficientairflowexhaustuseastraightrunorasfewelbowsaspossible.
 Ventunittotheoutsideonly.
 Two(2)peoplearerequiredforinstallation.
 Remove the range hood from the carton packaging and place on a flat surface for
assembly.


ELECTRICALREQUIREMENTS

CAUTION:THISAPPLIANCESHOULDBEPROPERLYGROUNDED. 

 This hood mustbe power supplied from 110‐120 V, 60 Hz  source and connected to an
individual,properlygroundedcircuit(3‐prongoutlet).
 If the electrical supply does not meet above requirements, call a licensed electrician
beforeproceeding.
 Routehousewiringascloseaspossible
totheinstallationlocation,intheceilingorback
wall.
 Thehoodmustbeconnectedtothehousewiring inaccordancewiththelocalcodesand
norms.


WALLFRAMINGFORADEQUATESUPPORT

This vent hood is heavy.Adequate  structure and support must be provided in all types of
installations.Ifmountingondrywall,thehoodmustbesecuretoverticalstudsinthewallortoa
horizontalsupport.



