Mistral MPP274S - Cabinet Installation Clearances

Dimensions
Built-In Hood 27.6‘’ (70.1 cm)
Dimension Dimension
A 27 1/2’’ (68.6
)
E 9 7/8’’ (25.1 cm)
B 26’’ (66 cm) F 5/8’’ (1.6 cm)
C 5/8’’ (1.6 cm) G 12 3/8’’ (30.43 cm)
D 10 1/4’’ (25.4 cm) H 6’’ (15.25 cm)
The information contained herein is based on sources that we believe to be reliable, but is not guaranteed by us, may be
incomplete and/or may change without notice.
) 651-2534
A Floortoceilingheight variable
B
Floortocountertopheight
(standard)
36’’
C
Recommendedheightbetween
cookingsurfaceandbottomofthe
hood
28’’to30’’
D Hoodheight 97/8’’
E Cabinetheight(minimum) 12’’
Installation
Duct transition
Top 6’’ rond
9
