 SUPERSeries·User’sManual
-9-

































No.

Name
1 Collet
2 CeramicNozzle
3 Cap
4 Earthclamp
5 Argonweldingtorch

6 Gas-pressureMeter

7 Gasregulator
8 GasCylinder
9 GasHose
10 GroundScrew
11 Fan
12 Powercable
13 Powerswitch
 SUPERSeries·User’sManual
-6-


INSTALLMENT&OPERATION

Theweldingmachineisequippedwithpowervoltagecompensationdevice.When
powervoltagefluctuatesbetween±15%ofratedvoltage,itcanstillworknormally.

Asusinglongcables,inordertoreducethevoltagedrop,cableofbiggersectionis
suggested.Ifcableistoolong,itmayaffecttheperformanceofthepowersystemas
wellasotherproperties,sowerecommendyoutousetheconfiguredlength.
1. Besuretheventsarenotblocked,lestcoolingsystemwillnotwork.
2. Well connect theprotectiongas source. Gassupplyincludesgascylinder,argon
regulatorandgashose.Connectingpartofgashoseshouldbefastenedwithhose
clamptopreventfromleakinggasorairadmission.
3. Useinductingcablewiththesectionnotsmallerthan6mm²toconnectthehousing
totheground.Thewayisfromtheground-connectingscrewtotheearthdevice.



























