19 Install the halyard of the rst span.
Make 3 turns of the halyard around the
pulley. Use the hole in the pulley to secure
the halyard with a knot.
Winding direction.
Above the pulley.
Note : it will be done on the right guide and on the left guide of the rst span.
Halyard length = 4 x total projection
20 Open the tarp.
= =
1/2 oor projection
IMPORTANT
Check that the fabric is centered in the guides.
To re-center the fabric, open it fully and roll it up,
making sure it is centered correctly with respect
to the guides.
Let the halyard hang
IMPORTANT
In some conguration, the halyard may already
be pre-assembled.
