MITJAVILA V2 - 22. Load Bar Guidance Through Guides; Angle, Fit, and Engage Load Bar; Manually Slide Load Bar

Page 22
Engage in the other guide with a re-
verse rotation movement to the rst
one.
22 Guide the load bar through the guides.
1
2
3
1 Angle the load bar.
2 Fit in a guide.
3
Manually slide the load bar along the guides to validate the movement.4
In position
