23 Cable routing.
Note : do on both sides.
For reasons of understanding, certain items
have been removed from the drawing. The ha-
lyard is drawn in two different colors for reasons
of understanding.
A Pre-assembled.
1 2 3
4 5 6
7
PO20
PLT2760
PLO5149
AC12
64
1
2
3
5
7
