Installing the Loop Handle Assembly
• Fix the loop-handle to the shaft over the rubber block provided. Adjust to a comfortable
working position then tighten the xing screws securely.
Upper Handle
Rubber Block
Fixing Screws
Drive Shaft
Lower Handle
To Gear Case
