Original Instructions Version June13
Warnings in the Manual
This mark indicates instructions which must be followed in order to prevent accidents which could lead to
serious bodily injury or death.
This mark indicates instructions which must be followed or it leads to mechanical failure, breakdown, or
damage.
This mark indicates hints or useful directions in the use of the product.
PRODUCT DESCRIPTION
This Multi-Tool unit is a 2 stroke fast running power tool and is designed to be used in a domestic
application with the attachments supplied. The Brushcutter attachment is designed for cutting grass and
light brush, the hedge trimmer attachment for trimming new growth on hedges and the Pole Pruner for
cutting up to 4” branches.
IMPORTANT
!
NOTE
Component Location
1. Fuel tank – 2 stroke mixture
2. Engine starter.
3. Carburettor / air lter.
4. Safety lever.
5. Throttle control lever.
6. Ignition switch.
7. Harness hanger.
8. Loop handle
8A Rubber hand grip
9. Transmission shaft.
10. Attachment shaft.
11. Safety guard.
12. Gear box.
13. Nylon head.
14. Optional cutting blade.
15. Cutting blade.
16. Gear box.
17. Attachment shaft.
18. Attachment shaft.
19. Gear box.
20. Oil tank for lubrication.
21. Guide Bar.
22. Saw chain.
23. Extension Shaft
