28PP Pole Pruner
35
Original Instructions Version December 15
Parts List - Body
ID No. Part Number Description
1 MITBC431D.02.00-3 CLAMP
2 MITBC430D.03.02-00 HARNESS CLAMP ASSEMBLY
3 MIGB/T2671.2 M5X20 SCREW M5X20
4 MITBC430D.03.00-2 CLAMP
5 MIGB/T6170 M5 NUT M5
6 MITBC431SJ.03.02-00 OUTER SHAFT - UPPER
7 MITBC431DJ.03.03-00 COUPLING ASSEMBLY
8 MIGB/T2671.2 M5X25 SCREW M5X25
9 MIGB/T2671.2 M5X12 SCREW M5X12
10 MIGB/T5781 M6X50 BOLT M6X50
11 MIGB/T96 M6 WASHER M6
12 MITBC431DJ.03.03-7 LOCK KNOB
13 MIGB/T923 M6 NUT M6
14 MITBC431DJ.03.03-3 LOCK ASSY
15 MITBC431M.03.01-02 DRIVE SHAFT
16 MITBC431M.03.01-00 EXTENSION ASSEMBLY
17 MITBC431DJ.03.01-2 LIMIT SLEEVE
18 MITBC431DJ.03.03-00 COUPLING ASSEMBLY
19 MIGB/T2671.2 M5X25 SCREW M5X25
20 MIGB/T2671.2 M5X12 SCREW M5X12
21 MIGB/T5781 M6X50 BOLT M6X50
22 MIGB/T96 M6 WASHER M6
23 MITBC431DJ.03.03-7 LOCK KNOB
24 MIGB/T923 M6 NUT M6
25 MITBC431DJ.03.03-3 LOCK ASSY
56 MITBC431S.05.01-1 FRONT HANDLE
57 MIGB/T6170 M5 NUT M5
58 MITBC431S.05.01-2 HANDLE BASE
59 MITBC431S.05.01-3 HANDLE CLAMP
61 MIGB/T2671.2 M5X28 SCREW M5X28
