Mitox 455CSX - Component Location

455CSX / 515CSX PREMIUM Chainsaw
2
Original Instructions Version July 18
455CSX/515CSX_030718
Component Location
1
2
3
4
5
13
6
7
8
9
10
11
12
14
15
16
19
17
18
20
21 22
1. Saw chain
2. Guide bar
3. Chain brake
4. Front handle
5. Air filter cover
6. Lock Lever
7. Engine Switch
8. Throttle lock lever
9. Rear Handle
10. Throttle Trigger
11. Fuel Level Window
12. Fuel Tank Cap
13. Choke Lever
14. Starter Handle
15. Chain Oil Tank Cap
16. Guide Bar Cover
17. Fuel Primer Bulb
18. Integrated Tool
19. Decompression Valve*
20. Clutch Cover
21. Chain Tensioner
22. Felling Claws
(*not on 455 or 515CSX)
