455CSX / 515CSX PREMIUM Chainsaw
30
Original Instructions Version July 18
455CSX/515CSX_030718
455CSX Parts - Engine
NO. PART NO. DESCRIPTION QTY
1 MI01.01.2141 SCREW M5x20 10
2 MIA46.5101.0601-5 CYLINDER 1
3 MIA36.0102.0102 PRESSURE NOZZLE 1
4 MIA45.0103.0001 PISTON RING 2
5 MIA45.5103.0200 PISTON 1
6 MIA38.0303.0003 CIRCLIP 2
7 MIA52.5103.0005 ANTI-FRICTION WASHER 2
8 MIA50.1103.0004 NEEDLE BEARING ∅13x∅10x12.5 1
9 MIA50.1103.0002 PISTON PIN 1
10 MIA50.1101.0008-1 CYLINDER GASKET 1
14 MIA50.1102.0202 OIL SEAL ∅12x∅20x5 1
15 MIF76.0101.0013 SCREW M5x20 3
16 MI03.01.2.185 TANK ABSORBER 2
17 MIA52.5102.0007 HEAT SHIELD 1
18 MIA50.1102.0201-14 LEFT CRANKCASE 1
19 MI01.05.0071 PIN 5x10 2
20 MIA50.1102.0002 CRANKCASE GASKET 1
21 MI01.05.1260 BEARING 6202 1
22 MIA50.1103.0100 CRANKSHAFT 1
23 MIA50.1102.0102 BEARING 1
24 MIA50.1102.0103 OIL SEAL ∅20x∅30x5 1
25 MIA50.1102.0101-14 RIGHT CRANKCASE 1
26 MIA42.0102.0300 VENT NOZZLE 1
27 MIA42.0102.0005 PIN 1
28 MIA42.0102.0006 PIN 1
29 MIA42.0102.0004 PIN 1
30 MI01.05.0072 OIL PUMP PIN ∅5x14 1
31 MIA50.1102.0001 CHAIN CATCHER 1
32 MI01.01.3292 SCREW M6x20 3
33 MI03.01.2.173 O RING ∅6x2 1
34 MIA42.0112.0008 TENSIONER SCREW 1
35 MIA42.0112.0007 TENSIONER GEAR 1
36 MIA42.0112.0005-1 GEAR COVER 1
37 MI01.01.3303 SCREW M5x12 2
38 MIA50.1112.0006 TENSIONER BLOCK 1
NO. PART NO. DESCRIPTION QTY
39 MIA42.0112.0006-1 POSITION BLOCK 1
40 MIA50.1101.0014 SPIKED BUMPER 1
41 MIA42.0100.0008 SCREW M5x16 12
42 MIA50.5100.0007 BOLT AYM8-M8x30 2
181 MIA50.5100.0100 OIL TANK CAP ASSEMBLY 1
