Mitox 455CSX - Page 36

455CSX / 515CSX PREMIUM Chainsaw
36
Original Instructions Version July 18
455CSX/515CSX_030718
455CSX Parts - Brake Assembly
NO. PART NO. DESCRIPTION QTY
109 MIA50.5112.0003 SCREW SHAFT 1
110 MIA42.0112.0013 RETURN SPRING FIXTURE 1
111 MIA42.0112.0011 RETURN SPRING 1
112 MIA42.0112.0012-1 RETURN SPRING COVER 1
113 MIA50.5112.0300-6 CHAIN BRAKE LEVER 1
114 MIA50.5112.0002-14 INSERT 1
115 MIA42.0112.0200 BRACKET 1
116 MI01.04.1041 E RING ∅5 2
117 MIA42.0114.0001-1 OIL PUMP COVER 1
118 MIA52.5114.0006 SCREW M5x8 1
119 MIA42.0114.0004 OIL TUBE 1
120 MIA42.0114.0003 OIL FILTER SPRING 1
121 MIA42.0114.0002-1 OIL FILTER 1
122 MIA42.0114.0100 OIL PUMP 1
123 MIA42.0114.0005 SPRAY NOZZLE 1
124 MI01.05.0231 POSITION PIN ∅3x8 1
125 MIA42.0112.0004 BRAKE BAND 1
126 MIA42.0112.0003 BRAKE SPRING 1
127 MIA41.1101.0700-2 WORM 1
128 MIA42.0101.0011 WASHER 1
129 MIA42.0101.0500 CLUTCH 1
130 MIA50.1101.0010 WASHER ∅17.8x∅10.1x0.8 1
131 MIA50.1101.0016 CLUTCH DRUM 1
132 MIA45.0101.0030 POWER MATE .325 1
133 MIA42.0101.0600 NEEDLE BEARING ∅10x∅14x13 1
134 MIA42.0101.0014 ANTI-FRICTION WASHER 1
135 MI06.03.160 E RING ∅8 1
136 MIA50.1112.0003 BRAKE SPRING COVER 1
137 MIA52.5112.0008 COVER SEAL SUBPLATE 1
138 MIA50.5112.0100-2 CLUTCH COVER 1
140 MIA50.5112.0001-14 DISCHARGE COVER 1
185 MI07.04.1.05.414 OREGON SAW CHAIN 21BPX072X 1
186 MI07.04.1.04.405 OREGON GUIDE BAR 188PXBK095 1
187 MI07.04.1.10.424 GUIDE BAR COVER 18" 1
