515CSX Parts - Recoil Assembly
NO. PART NO. DESCRIPTION QTY
93 MIA41.1110.0003 STARTER HANDLE 1
94 MIA41.1110.0002 PROTECTION RING 1
96 MIA50.5100.0008 TAPPING SCREW ST4.8x13 2
97 MIA38.0310.0003 STARTER ROPE ∅3.0x920 1
99 MIA45.0130.0200 STARTER SPRING 1
100 MIA45.0130.0001 ROPE WHEEL 1
101 MIA45.0130.0003 DAMPER SPRING 1
102 MIA50.5110.0102 STARTER RATCHET 1
103 MIA45.0130.0004 WASHER ∅5x∅16x1.5 1
104 MIA50.1113.0102-1 FLOW GUIDING COVER 1
105 MI02.05.92 SWITCH 1
106 MIA52.5106.0400 GROUND WIRE 1
107 MI01.03.0073 NUT M8x1 1
108 MIA45.0101.0036 SEMI-CIRCLE KEY 1
109 MIA50.5106.0200 IGNITION 1
110 MIA50.5112.0500 BUSH 1
111 MIA45.0106.0500 SPARK PLUG 1
112 MIA42.0106.0100 FLYWHEEL 1
182 MIA50.5110.0000 STARTER ASSEMBLY 1
184 MIA41.1100.0008 SCREW M5X25 4
