515CSX Parts - Fuel Tank Assembly
NO. PART NO. DESCRIPTION QTY
144 MIA50.5111.0200-15 REAR HANDLE COVER 1
145 MIA50.5111.0005-7 THROTTLE TRIGGER LOCK-OUT 1
146 MIA50.1111.0006 THROTTLE TRIGGER SPRING 1
147 MIA50.5111.0007-1 GUIDE 1
148 MIA50.1111.0008-1 LINK 1
149 MIA50.1111.0004 THROTTLE TRIGGER SPRING 1
152 MIA50.1111.0001 VENT CAP 1
153 MIA42.0111.0011 SPRING 1
154 MIA45.0102.0202 VENT VALVE 1
155 MIA50.1100.0002-2 REAR ABSORBER SPRING BASE M6 2
156 MIA50.1100.0001 REAR ABSORBER SPRING 2
157 MIA50.5100.0010 TAPPING SCREW ST4.8x25 2
158 MIA50.1100.0003-1 REAR ABSORBER SPRING BASE M7 2
159 MIA50.1111.0009 FUEL TUBE 1
160 MIA42.1111.0010 CIRCLIP 1
161 MI04.01.01.09808 FUEL FILTER 1
162 MI03.01.2.154 RETURN PIPE ∅2.5x∅6x130 1
163 MIA45.0111.0009 RETURN PIPE BASE 1
164 MIA50.5111.0100-6 REAR HANDLE 1
165 MIA41.1111.0002-3 BOTTOM COVER 1
166 MIA41.1100.0014 STRAP SPRING 1
167 MIA41.1100.0013 FIXTURE SPRING 1
168 MIA41.1100.0012 SPARK PLUG WRENCH 1
169 MIA50.1111.0003-8 THROTTLE TRIGGER 1
170 MIA50.1100.0005-2 SPRING BASE 2
171 MIA50.1100.0004 FRONT ABSORBER SPRING 1
172 MIA50.5100.0201-1 FRONT HANDLE 1
183 MIA41.1111.0300 FUEL TANK CAP ASSEMBLY 1
