<Table 3-2>
Optional extras
●Wireless Remote Controller PAR-WT50R-E ●
Tank thermistor (THW5) (30 m)
PAC-TH011TKL-E *1 The environment must be frost-free.
●Wireless Receiver PAR-WR51R-E ●Thermistor PAC-TH011-E *2 Cooling mode is not available in low outdoor temperature.
●Remote Sensor PAC-SE41TS-E ●High temperature thermistor PAC-TH011HT-E If you use our system in cooling mode at the low ambient temperature (10°C or below), there are some risks of plate heat exchanger breaking by frozen water.
●Tank thermistor (THW5) (5 m) PAC-TH011TK-E ●ecodan Wi-Fi Interface PAC-WF010-E
●
2-zone kit PAC-TZ01-E
Model name (Service Ref.)
EHSD-
MECR1.UK
EHSD-
MCR1.UK
EHSD-
VM2CR1.UK
EHSD-
YM9CR1.UK
EHSC-
MECR1.UK
EHSC-
VM2CR1.UK
EHSC-
VM2ECR1.UK
EHSC-
VM6CR1.UK
EHSC-
VM6ECR1.UK
EHSC-
YM9CR1.UK
EHSC-
YM9ECR1.UK
EHSC-
TM9CR1.UK
ERSD-
VM2CR1.UK
ERSC-
MECR1.UK
ERSC-
VM2CR1.UK
EHPX-
VM2CR1.UK
EHPX-
VM6CR1.UK
EHPX-
YM9CR1.UK
EHSD-
MECR2.UK
EHSD-
MCR2.UK
EHSD-
VM2CR2.UK
EHSD-
YM9CR2.UK
EHSC-
MECR2.UK
EHSC-
VM2CR2.UK
EHSC-
VM2ECR2.UK
EHSC-
VM6CR2.UK
EHSC-
VM6ECR2.UK
EHSC-
YM9CR2.UK
EHSC-
YM9ECR2.UK
EHSC-
TM9CR2.UK
ERSD-
VM2CR2.UK
ERSC-
MECR2.UK
ERSC-
VM2CR2.UK
EHPX-
VM2CR2.UK
EHPX-
VM6CR2.UK
EHPX-
YM9CR2.UK
Overall unit dimensions 800 × 530 × 360 mm (Height × Width × Depth)
Weight (empty) 38 kg 43 kg 44 kg 45 kg 42 kg 48 kg 43 kg 49 kg 44 kg 49 kg 44 kg 49 kg 45 kg 43 kg 49 kg 37 kg 38 kg 38 kg
Weight (full) 44 kg 49 kg 50 kg 51 kg 49 kg 55 kg 50 kg 56 kg 51 kg 56 kg 51 kg 56 kg 51 kg 50 kg 56 kg 42 kg 43 kg 43 kg
Water volume of heating circuit in the unit 5.2 kg 5.2 kg 5.2 kg 5.2 kg 6.1 kg 6.1 kg 6.1 kg 6.1 kg 6.1 kg 6.1 kg 6.1 kg 6.1 kg 5.5 kg 6.4 kg 6.4 kg 4.5 kg 4.5 kg 4.5 kg
Plate heat exchanger (MWA2) — — — —
— — — —
Plate heat exchanger (MWA1)
— — — — — — — — — — — — —
Cooling mode NOT available Available NOT available
Unvented expansion
vessel(Primary heating)
Nominal volume — 10 L — 10 L — 10 L — 10 L — 10 L — 10 L
Charge pressure — 1 bar — 1 bar — 1 bar — 1 bar — 1 bar — 1 bar
Safety
device
Water
circuit
(Primary)
Control thermistor 1–80°C
Pressure relief valve (Red) 0.3 MPa (3bar)
Flow sensor Min ow 5.0 L/min
Booster
heater
Manual reset thermostat — 90°C — 90°C — 90°C
Thermal Cut-out (for dry run prevention) — 121°C — 121°C — 121°C
Primary circuit circulating Pump Grundfos UPM2 15–70 130 Grundfos UPM2K 15–75 130 Grundfos UPM2 15–70 130
Connections
Water 28 mm compression (primary circuit) G1 (Male)
28 mm compression
(primary circuit)
Refrigerant
(R410A)
Liquid 6.35 mm 9.52 mm 6.35 mm 9.52 mm —
Gas 12.7 mm 15.88 mm 12.7 mm 15.88 mm —
Target temperature
range
Flow
temperature
Heating 25–60°C
Cooling — 5–25°C —
Room
temperature
Heating 10–30 °C
Cooling — NOT available —
Guaranteed operat-
ing range
Ambient *1 0–35°C (
80%RH)
Outdoor
temperature
Heating See outdoor unit spec table.
Cooling —
See outdoor unit spec table
(minimum 10°C). *2
—
Electrical data
Control board
Power supply (Phase,
voltage, frequency)
~/N, 230 V, 50 Hz
Breaker (when pow-
ered from independent
source)
10A
Booster
heater
Power supply (Phase,
voltage, frequency)
— —
~/N, 230 V,
50 Hz
3~, 400 V,
50 Hz
—
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
3~, 400 V,
50 Hz
3~, 400 V,
50 Hz
3~, 230 V,
50 Hz
~/N, 230 V,
50 Hz
—
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
3~, 400 V,
50 Hz
Capacity — — 2 kW
3kW+
6 kW
— 2 kW 2 kW
2 kW+
4 kW
2 kW+
4 kW
3kW+
6 kW
3kW+
6 kW
3kW+
6 kW
2 kW — 2 kW 2 kW
2 kW+
4 kW
3kW+
6 kW
Current — — 9 A 13 A — 9 A 9 A 26 A 26 A 13 A 13 A 23 A 9 A — 9 A 9 A 26 A 13 A
Breaker — — 16 A 16 A — 16 A 16 A 32 A 32 A 16 A 16 A 32 A 16 A — 16 A 16 A 32 A 16 A
Sound pressure level 28 dB(A)
Sound power level 40 dB(A)
