Parameters (D) Operation command and frequency command
FR-F800 5 - 119
5.6.1 Operation mode selection
Select the operation mode of the inverter.
The mode can be changed among operations using external signals (External operation), operation
by operation panel or parameter unit (PU operation), combined operation of PU operation and Ex-
ternal operation (External/PU combined operation), and Network operation (when RS-485 terminals
or communication option is used).
The following table lists valid and invalid commands in each operation mode.
The priority of frequency commands when Pr. 79 = "3" is "multi-speed operation (RL/RM/RH/REX)
> PID control (X14) > terminal 4 analog input (AU) > digital input by operation panel".
Pr. Name Initial value Setting range Description
79
D000
Operation mode selection 0 0 to 4, 6, 7 Selects the operation mode.
Pr. 79
setting
Description
LED display
:OFF
:ON
Refer
to
page
0
(initial
value)
Use the External/PU switchover mode (PU/EXT key) to switch between the
PU and External operation mode.
At power ON, the inverter is in the External operation mode.
PU operation mode
External operation mode
NET operation mode
5-122
Operation mode Frequency command Start command
1
PU operation mode
fixed
Operation panel or
parameter unit.
FWD or REV key on
operation panel or
parameter unit
PU operation mode
5-123
2
External operation
mode fixed.
The operation can be
performed by switching
between the External
and NET operation
modes.
External signal input
(terminal 2 and 4, JOG,
multi-speed selection,
etc.)
External signal input
(terminal STF, STR)
External operation mode
NET operation mode
5-122
3
External/PU combined
operation mode 1
Operation panel/
parameter unit or
external signal input
(multi-speed setting,
terminal 4)
External signal input
(terminal STF, STR)
External/PU combined
operation mode
5-123
4
External/PU combined
operation mode 2
External signal input
(terminal 2 and 4, JOG,
multi-speed selection,
etc.)
FWD or REV key on
operation panel or
parameter unit
5-124
6
Switchover mode
Switching of PU, External, and NET operation modes can be performed
during operation.
PU operation mode
External operation mode
NET operation mode
5-124
7
External operation mode (PU operation interlock)
X12 signal ON: Switchover to PU operation mode enabled (during External
operation, output shutoff)
X12 signal OFF: Switchover to PU operation mode disabled
5-124
Tab. 5-49: Settings of Pr. 79
