APPX
Appendix 1 Optional Items
129
A
APPENDICES
Appendix 1 Optional Items
Connector/terminal block converter modules
Included products
Availability of the connector/terminal block converter module
*1 Available only when using a positive common.
• The number of connectable I/O points is 32 for all the connector/terminal block converter modules. An I/O
module with 64 points requires two sets of the connector/terminal block converter module and its cable.
• The terminal screws (M3.5) of the module require a tightening torque of 0.78Nm.
Model Description Weight Applicable wire
size
Applicable solderless terminal
A6TBXY36 For positive common type input module
For sink/source type output module
(standard type)
0.4kg 0.75 to 2 1.25-3.5 (JIS)
1.25-YS3A
V1.25-M3
V1.25-YS3A
2-3.5 (JIS)
2-YS3A
V2-S3
V2-YS3A
A6TBXY54 For positive common type input module
For sink/source type output module
(2-wire type)
0.5kg
A6TBX70 For positive common type input module
(3-wire type)
0.6kg
Product Description Quantity
M425 screw A screw for mounting the connector/terminal block converter module onto a panel 2
Product Model A6TBXY36 A6TBXY54 A6TBX70
Input module
*1
RX41C4 
RX42C4 
RX41C6HS 
RX61C6HS 
RX71C4 
RX72C4 
Output module RY41NT2P 
RY41NT2H 
RY42NT2P 
RY41PT1P 
RY41PT2H 
RY42PT1P 
I/O combined module RH42C4NT2
P
Input side
*1

Output side 

Mitsubishi Electric MELSEC iQ-R RX41C4-TS Specifications

General

Model	RX41C4-TS
Product Line	MELSEC iQ-R
Category	I/O Systems
Terminal block type	Spring clamp terminal block
Rated voltage	24 VDC
Ambient temperature	0 to 55 °C
Protective structure	IP20
Operating Temperature	0 to 55 °C
Applicable module	RX41
Rated current	0.5 A
Insulation resistance	10 MΩ or more
Relative humidity	5 to 95% (non-condensing)
Weight	0.3 kg
Storage Temperature	-25 to 70 °C
Number of terminals	40
