Mitsubishi Electric MSZ-BT20VGK User Manual

● OPERATING INSTRUCTIONS ●
EN
EN-15
Indoor Outdoor
Cooling
Upper limit
32°C DB
23°C WB
46°C DB
—
Lower limit
21°C DB
15°C WB
-10°C DB
—
Heating
Upper limit
27°C DB
—
24°C DB
18°C WB
Lower limit
20°C DB
—
-15°C DB
-16°C WB
Note:
Rating condition
Cooling — Indoor: 27°C DB, 19°C WB
Outdoor: 35°C DB
Heating — Indoor: 20°C DB
Outdoor: 7°C DB, 6°C WB
Guaranteed operating range
SPECIFICATIONS
Model
Indoor
MSZ-BT20VG(K) MSZ-BT25VG(K) MSZ-BT35VG(K) MSZ-BT50VG(K)
Outdoor
MUZ-BT20VG MUZ-BT25VG MUZ-BT35VG MUZ-BT50VG
Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Power supply ~ /N, 230 V, 50 Hz
Capacity kW 2.0 2.5 2.5 3.15 3.5 3.6 5.0 5.4
Input kW 0.45 0.55 0.70 0.75 1.24 0.93 2.05 1.55
Weight
Indoor kg 9.0
Outdoor kg 23 24 35
Refrigerant fi lling capacity (R32) kg 0.45 0.50 0.70
IP code
Indoor IP 20
Outdoor IP 24
Permissible excessive
operating pressure
LP ps MPa 2.77
HP ps MPa 4.17
Noise level (SPL)
Indoor (Super High/
High/Med./Low/Silent)
dB(A)
43/37/30/
22/19
43/37/30/
23/20
43/37/30/
22/19
43/37/30/
23/20
46/38/31/
22/19
44/37/30/
23/20
46/40/36/
33/29
48/43/38/
33/29
Outdoor dB(A) 50 50 50 50 52 52 50 51
DB: Dry Bulb
WB: Wet Bulb
Indoor specifi cation for multi connection REGULATION (EU) 2016/2281
Model Indoor MSZ-BT20VG(K) MSZ-BT25VG(K) MSZ-BT35VG(K) MSZ-BT50VG(K)
Capacity
Cooling
Sensible kW 1.98 2.30 2.94 3.65
Latent kW 0.02 0.20 0.56 1.35
Heating kW 2.50 3.15 3.60 5.40
Input kW 0.024 0.024 0.031 0.037
Noise level
(Sound power level)
Super High/High/Med./Low/
Silent
dB(A) 57/51/44/36/33 57/51/44/36/33 60/52/45/36/33 60/54/50/47/43
Wi-Fi interface
Model MAC-577IF-E
Input Voltage DC12.7 V (from indoor unit)
Power consumption MAX. 2 W
Size H×W×D (mm) 73.5×41.5×18.5
Weight (g) 46 (including cable)
Transmitter power level (MAX.) 20 dBm @IEEE 802.11b
RF channel 1ch ~ 13ch (2412~2472 MHz)
Radio protocol IEEE 802.11b/g/n (20)
Encryption AES
Authentication WPA2-PSK
Software Version XX.00
For Declaration of Conformity, please go to the website below.
http://www.melcloud.com/Support
JG79Y675H02_01En.indd 15 2019/10/16 10:17:06

Mitsubishi Electric MSZ-BT20VGK Specifications

General

Cooling Capacity	2.0 kW
Heating Capacity	2.5 kW
Refrigerant	R32
Power Supply	220-240 V, 50 Hz
Indoor Unit Dimensions (W x H x D)	799 x 290 x 232 mm
Outdoor Unit Dimensions (W x H x D)	699 x 538 x 249 mm
Energy Star Rating Cooling	Not Available
Energy Star Rating Heating	Not Available
Energy Efficiency Ratio (EER)	Not Available
Noise Level (Indoor Unit)	21 dB(A)
