17
MXZ-3A54VA
NOTE: Electrical data is for outdoor unit only.
Indoor units
combination
Cooling capacity (kW)
Outdoor unit
power consumption
(kW)
Current
(A)
Power
factor
(%)
Unit A Unit B Unit C Total
22
2.2 - - 2.2 0.590 2.59 99
( 1.4 - 3.0 ) ( 0.420 - 0.740 )
25
2.5 - - 2.5 0.660 2.90 99
( 1.4 - 3.3 ) ( 0.420 - 0.830 )
35
3.5 - - 3.5 0.950 4.17 99
( 1.5 - 4.3 ) ( 0.430 - 1.180 )
42
4.2 - - 4.2 1.220 5.36 99
( 1.6 - 5.0 ) ( 0.450 - 1.420 )
50
5.0 - - 5.0 1.500 6.59 99
( 1.6 - 5.6 ) ( 0.480 - 1.660 )
22+22
2.2 2.2 - 4.4 1.180 5.18 99
( 2.0 - 5.4 ) ( 0.540 - 1.450 )
22+25
2.2 2.5 - 4.7 1.300 5.71 99
( 2.0 - 5.8 ) ( 0.540 - 1.630 )
22+35
2.08 3.32 - 5.4 1.600 7.03 99
( 2.0 - 6.8 ) ( 0.540 - 2.550 )
22+42
1.86 3.54 - 5.4 1.590 6.98 99
( 2.0 - 6.8 ) ( 0.540 - 2.490 )
22+50
1.65 3.75 - 5.4 1.580 6.94 99
( 2.0 - 6.8 ) ( 0.550 - 2.440 )
25+25
2.5 2.5 - 5.0 1.420 6.24 99
( 2.0 - 6.0 ) ( 0.540 - 1.750 )
25+35
2.25 3.15 - 5.4 1.600 7.03 99
( 2.0 - 6.8 ) ( 0.540 - 2.550 )
25+42
2.01 3.39 - 5.4 1.590 6.98 99
( 2.0 - 6.8 ) ( 0.540 - 2.490 )
25+50
1.8 3.6 - 5.4 1.580 6.94 99
( 2.0 - 6.8 ) ( 0.550 - 2.440 )
35+35
2.7 2.7 - 5.4 1.600 7.03 99
( 2.0 - 6.8 ) ( 0.540 - 2.550 )
35+42
2.4 3.0 - 5.4 1.560 6.85 99
( 2.0 - 6.8 ) ( 0.540 - 2.490 )
35+50
2.22 3.18 - 5.4 1.530 6.72 99
( 2.0 - 6.8 ) ( 0.550 - 2.440 )
42+42
2.7 2.7 - 5.4 1.530 6.72 99
( 2.0 - 6.8 ) ( 0.550 - 2.440 )
42+50
2.47 2.93 - 5.4 1.540 6.76 99
( 2.1 - 6.8 ) ( 0.550 - 2.390 )
50+50
2.7 2.7 - 5.4 1.550 6.81 99
( 2.1 - 6.8 ) ( 0.560 - 2.340 )
22+22+22
1.8 1.8 1.8 5.4 1.295 5.69 99
( 2.9 - 6.8 ) ( 0.670 - 1.770 )
22+22+25
1.72 1.72 1.96 5.4 1.295 5.69 99
( 2.9 - 6.8 ) ( 0.670 - 1.770 )
22+22+35
1.5 1.5 2.4 5.4 1.295 5.69 99
( 2.9 - 6.8 ) ( 0.670 - 1.770 )
22+22+42
1.38 1.38 2.64 5.4 1.280 5.62 99
( 2.9 - 6.8 ) ( 0.670 - 1.780 )
22+22+50
1.26 1.26 2.88 5.4 1.265 5.56 99
( 2.9 - 6.8 ) ( 0.680 - 1.790 )
22+25+25
1.64 1.88 1.88 5.4 1.295 5.69 99
( 2.9 - 6.8 ) ( 0.670 - 1.770 )
