19
MXZ-3A54VA
NOTE: Electrical data is for outdoor unit only.
Indoor units
combination
Heating capacity (kW)
Outdoor unit
power consumption
(kW)
Current
(A)
Power
factor
(%)
Unit A Unit B Unit C Total
22
3.3 - - 3.3 0.820 3.60 99
( 1.2 - 4.2 ) ( 0.380 - 1.090 )
25
3.6 - - 3.6 0.910 4.00 99
( 1.2 - 4.5 ) ( 0.380 - 1.190 )
35
4.0 - - 4.0 1.040 4.57 99
( 1.2 - 4.8 ) ( 0.380 - 1.300 )
42
5.4 - - 5.4 1.400 6.15 99
( 1.3 - 6.5 ) ( 0.370 - 1.800 )
50
6.8 - - 6.8 1.770 7.77 99
( 1.4 - 8.2 ) ( 0.370 - 2.300 )
22+22
3.3 3.3 - 6.6 1.500 6.59 99
( 1.8 - 7.2 ) ( 0.410 - 1.710 )
22+25
3.18 3.62 - 6.8 1.580 6.94 99
( 1.8 - 8.7 ) ( 0.410 - 2.350 )
22+35
2.62 4.18 - 6.8 1.580 6.94 99
( 1.8 - 9.0 ) ( 0.410 - 2.390 )
22+42
2.34 4.46 - 6.8 1.510 6.63 99
( 1.8 - 9.0 ) ( 0.400 - 2.300 )
22+50
2.08 4.72 - 6.8 1.440 6.32 99
( 1.8 - 9.0 ) ( 0.390 - 2.220 )
25+25
3.4 3.4 - 6.8 1.580 6.94 99
( 1.8 - 9.0 ) ( 0.410 - 2.390 )
25+35
2.83 3.97 - 6.8 1.580 6.94 99
( 1.8 - 9.0 ) ( 0.410 - 2.390 )
25+42
2.54 4.26 - 6.8 1.510 6.63 99
( 1.8 - 9.0 ) ( 0.400 - 2.300 )
25+50
2.27 4.53 - 6.8 1.440 6.32 99
( 1.8 - 9.0 ) ( 0.390 - 2.220 )
35+35
3.4 3.4 - 6.8 1.580 6.94 99
( 1.8 - 9.0 ) ( 0.410 - 2.390 )
35+42
3.09 3.71 - 6.8 1.510 6.63 99
( 1.8 - 9.0 ) ( 0.410 - 2.300 )
35+50
2.8 4.0 - 6.8 1.440 6.32 99
( 1.8 - 9.0 ) ( 0.410 - 2.220 )
42+42
3.4 3.4 - 6.8 1.440 6.32 99
( 1.8 - 9.0 ) ( 0.410 - 2.220 )
42+50
3.1 3.7 - 6.8 1.410 6.19 99
( 1.9 - 9.0 ) ( 0.380 - 2.130 )
50+50
3.4 3.4 - 6.8 1.390 6.10 99
( 1.9 - 9.0 ) ( 0.360 - 2.040 )
22+22+22
2.27 2.27 2.27 6.8 1.455 6.39 99
( 2.6 - 9.0 ) ( 0.500 - 2.120 )
22+22+25
2.17 2.17 2.46 6.8 1.455 6.39 99
( 2.6 - 9.0 ) ( 0.500 - 2.120 )
22+22+35
1.89 1.89 3.02 6.8 1.455 6.39 99
( 2.6 - 9.0 ) ( 0.500 - 2.120 )
22+22+42
1.74 1.74 3.32 6.8 1.380 6.06 99
( 2.6 - 9.0 ) ( 0.490 - 2.040 )
22+22+50
1.59 1.59 3.62 6.8 1.310 5.75 99
( 2.6 - 9.0 ) ( 0.480 - 1.960 )
22+25+25
2.08 2.36 2.36 6.8 1.455 6.39 99
( 2.6 - 9.0 ) ( 0.500 - 2.120 )
