71
Unit: mm
MXZ-4A71VA -
E1
,
E2
,
E3
,
E4
84
360
121
17.7 17.7360.6
396
3831
500
288233.163.2
31.316.8
1330 330
25
66.3
27.1
30840
710
440
45
315
23.1
Drainage holes 3- 33
4-10 x 21 Oval hole
Air out
Air in
Air in
Liquid pipe
6.35(flared)1/4
Gas pipe
9.52(flared)3/8(B,C,D unit)
12.7(flared)1/2(A unit)
D unit connection
C unit connection
B unit connection
A unit connection
Indoor and
outdoor
connect wiring
39 x 27 hole
REQUIRED SPACE
More than 100 mm
Open as a rule
More than 500 mm
if the front and both
sides are open
More than 100 mm
More than 200 mm if
there are obstacles to
both sides
Open as a rule
More than 500 mm if
the back, both sides
and top are open
More than 350 mm
