16
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27: (80˚F) W.B. 19: (66˚F) Outdoor : D.B. 35: (95˚F) W.B. 24: (75˚F)
Heating Indoor : D.B. 20: (68˚F) Outdoor : D.B. 7: (45˚F) W.B. 6: (43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling
Upper limit
D.B. 35˚C, W.B. 22.5˚C
D.B. 46˚C
Lower limit
D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating
Upper limit
D.B. 28˚C
D.B. 21˚C, W.B. 15˚C
Lower limit
D.B. 17˚C
D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
w If optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP50GA PCA-RP60GA PCA-RP71GA
Outdoor unit PUHZ-RP50VHA2 PUHZ-RP60VHA2 PUHZ-RP71VHA2
Cooling Capacity Btu/h 16
,
000 20
,
500 24
,
200
kW 4.7
(
2.3-5.4
)
6.0
(
2.7-6.7
)
7.1
(
3.3-8.1
)
Total input kW 1.67 1.63 2.14
EER 2.81 3.68 3.32
Energy label class C A A
SHF 0.76 0.86 0.74
Heating Capacity Btu/h 18
,
800 23
,
900 27
,
300
kW 5.5
(
2.5-6.6
)
7.0
(
2.8-8.2
)
7.6
(
3.5-10.2
)
Total input kW 1.71 2.03 2.23
COP 3.22 3.45 3.41
Energy label class C B B
Booster heater kW - - -
Power supply Phase [ 1
Cycle Hz 50
Voltage V 230
Breaker size A 16 25
Indoor unit Air flow CMM 10-11-12-13 14-15-16-18
(
Low-Medium2-Medium1-High
)
CFM 355-390-425-460 495-530-565-635
External pressure Pa 0 0
Sound level dB
(
A
)
37-38-40-42 37-39-41-43
(
Low-Medium2-Medium1-High
)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 1000 1310
D : mm 680
H : mm 210
W : inch 39-3/8 51-9/16
D : inch 26-3/4
H : inch 8-1/4
Weight kg 27 34
lbs 60 75
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 35 55
CFM 1
,
240 1
,
940
Sound level at cooling dB
(
A
)
44 47
Sound level at heating dB
(
A
)
46 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800 950
D : mm 300+23 330+30
H : mm 600 943
W : inch 31-1/2 37-3/8
D : inch 11-13/16 + 7/8 13 + 1-3/16
H : inch 23-5/8 37-1/8
Weight kg 45 75
lbs 99 165
Refrigerant pipe size Gas side O.D. mm 12.7 15.88
inch 1/2 5/8
Liquid side O.D. mm 6.35 9.52
inch 1/4 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 50
2-4. CEILING SUSPENDED TYPE
