11
OCH809A
3
SPECIFICATIONS
Service Ref.
PUZ-SWM
60VAA 80VAA 80YAA 100VAA 100YAA 120VAA 120YAA 140VAA 140YAA
OUTDOOR UNIT
Power source (Phase, cycle, voltage)
Single 50 Hz, 230 V
3-Phase 50 Hz,
400 V
Single 50 Hz,
230 V
3-Phase 50 Hz,
400 V
Single 50 Hz,
230 V
3-Phase 50 Hz,
400 V
Single 50 Hz,
230V
3-Phase 50 Hz
400V
Max. current A 13.5 17.0 8.0 22.0 9.0 28.0 12.0 28.0 12.0
External nish Powder paint on Magnelis
<RAL2609005 (FRONT/ BASE RAL0002500)>
Refrigerant control Linear Expansion Valve
Compressor Hermetic
Model
DVB28FECMT DVB28FEDMT DVB28FECMT DVB28FEDMT DVB28FECMT DVB28FEDMT DVB36FEAMT DVB36FEBMT
Motor output kW 2.2 3.6
Starter type Inverter
Protection devices HP switch, Discharge thermo,Overcurrent detection,
Comp. surface thermo, Thermal protector
Crankcase heater W —
Heat exchanger Plate n coil
Fan Fan (drive) × No. Propeller fan x 1
Fan motor output
kW 0.200
Airow
m
3
/min (CFM)
58 (2050) 62 (2190) 60 (2120) 60 (2120)
Defrost method Reverse cycle
Sound power level Heating dB 54 58
Dimensions W mm (inch) 1050 (41-3/8)
D mm (inch) 480 (18-7/8)
H mm (inch) 1040 (40)
Weight kg (lb) 104.5 (231) 113.5 (251) 105.5 (233) 113.5 (251) 112 (247) 124.5 (275) 113.5 (251) 124.5 (275)
Refrigerant R32
Quantity chargeless kg (lb) 1.8 (3.97)
Oil (Model) L 0.9 (FW68CA)
Refrigerant piping
Pipe size OD Liquid mm (inch) 6.35 (1/4F)
Gas mm (inch) 12.7 (1/2F) or 15.88(5/8F)
*1
Connection
method
Indoor side Flared
Outdoor side Flared
Between the
indoor & outdoor
Height difference Maximum 30 m
Piping length 50 m 30 m (50 m
*2
)
*1 When connecting to a reversible indoor unit for cooling operation, please use MAC-001FN-E and connect ø15.88 gas pipe. Otherwise, the cooling capacity may be down.
*2 If used as heating only.
To Next Page
