PAGE 49
Ref # Part # Part Name & Description [#]
MODEL: WD-Y57 / WD-Y65 / WD-57732 / WD-65732 / WD-73732
[#] Model Legend: (a) WD-57732, (b) WD-65732, (c) WD-73732, (d) WD-Y57, (e) WD-Y65
Ref # Part # Part Name & Description [#]
TU100 295P540020 TUNER-NTSC/ATSC
TU101 295P540030 TUNER-NTSC/ATSC
X1500 285P459080 QTZ-CRYST - 25.140MHZ
X2296 285P459090 QTZ-CRYST - 28.322MHZ
X2M47 285P459050 QTZ-CRYST - SM-49 20.00MHz
X7A13 285P459040 QTZ-CRYST - 16MHZ
X7G01 285P391030 OSC - 74.175824MHZ
X7G02 285P431040 QTZ-CRYST - 27.00MHz
X7P09 285P459020 QTZ-CRYST - 8MHZ
X7R01 285P459030 QTZ-CRYST - 10MHZ
X8001 285P464020 QTZ-CRYST - 26.1621MHz
X8201 285P403020 QTZ-CRYST - 32.768MHZ
X8301 285P464010 QTZ-CRYST - 7.3728MHZ
X8402 285P464040 QTZ-CRYSTAL - 24.576MHz
X8403 285P464040 QTZ-CRYSTAL - 24.576MHz
X8501 285P464030 QTZ-CRYSTAL - 18.24MHz
X8G01 299P311010 CERAMIC-OSC - CSTCG24M0
X8H26 285P426050 QTZ-CRYST - 10.00MHz
Z7K01 938P005010 UNIT-PREAMP - GP1UM283QK
PRINTED CIRCUIT BOARDS
934C223001 ASSY-PWB-TERMINAL de
934C223002 ASSY-PWB-TERMINAL abc
934C224004 ASSY-PWB-SIGNAL
934C225002 ASSY-PWB-DM ab
934C225003 ASSY-PWB-DM c
934C225007 ASSY-PWB-DM de
934C228003 ASSY-PWB-POWER
934C229001 ASSY-PWB-INTERFACE c
935D889001 ASSY-PWB-FRONT
935D890002 ASSY-PWB-PREAMP
935D891001 ASSY-PWB-SW-LAMP
935D893001 ASSY-PWB-E2P
935D894001 ASSY-PWB-CONT 1 c
935D902001 ASSY-PWB-CONT2 abde
935D903001 ASSY-PWB-CONT3 abde
955C289001 ASSY-PWB-ENG-PWR c
COSMETIC PARTS
716C044010 BADGE - BRAND abde
760A019020 INLAY TERMINAL abc
760A019030 INLAY TERMINAL de
760C789010 INLAY-FRONT CONSOLE abde
ACCESSORIES
242D483020 IR-MOUSE
290P137010 REMOTE-CONTROL
I/B WDY57 GUIDE-OWNER
I/QR WD757 QR GUIDE
